LINX 3.0 – 03 | BeagleBone Black Setup

This tutorial describes the process of setting up a BeagleBone Black as a LabVIEW target using LINX.

Categories: Beginner

Originally published at https://www.hackster.io/labview-makerhub/linx-3-0-03-beaglebone-black-setup-70fa71.

  • Connect
    Ethernet
    to the BBB (BeagleBone Black).
  • Connect the BBB to the PC via USB.
  • If this is the first time connecting the BBB to the PC, open the BBB mass storage device from My Computer and launch the START html page.
  • Scroll down to
    Section 2
    and install the correct driver for the PC operating system.
  • Launch LabVIEW and open the Target Configuration Wizard from
    Tools»MakerHub»LINX»Target Configuration
    .
  • Enter the BBB Hostname or IP and a username and password with root privileges and click
    connect
    .
  • Default
    IP Address
    for the BBB USB/Ethernet device is ‘192.168.7.2’.
  • Default
    Username
    is ‘root’
  • Default
    Password
    is empty.
  • Click the
    Install Software
    tab.
  • Click
    Install
    .
  • Review any warnings and complete the installation.
